PRESENTATION OF THE CRAWLER QUICKRUN WP1080 G2 VARIATOR

With its G2 version, the Hobbywing Quicrun WP1080 is the first ESC equipped with a true “ Car Mode ”. This means that the direction of the motor can be switched in real time. This is done using the AUX channel on the transmitter and guarantees a unique driving experience that has never been seen before.
The strength of the engine brake can also be adjusted in real time and via another AUX channel.
Compared to the previous model, the Quicrun WP1080 G2 controller offers up to 8.4V at 6A. 15 adjustable parameters and over 90 values also ensure that the controller can be completely adapted to your own needs.

FEATURES OF THE CRAWLER QUICKRUN WP1080 G2 VARIATOR

Specially designed for 1/10 crawlers
BEC: 4 A continuous and up to 6 A at maximum load, adjustable to 6 V, 7.4 V or 8.4 V
Waterproof to IP67
15 editable parameters
Perfectly adjustable engine brake
Separate programming port
Small, light and yet robust
XT60 connector installed
Power: 80/400A
Compatible: Lipo 2S and 3S
Dimensions: 37.2x31.9x18.4mm
Connector:XT60
Weight: 70.20gr

PRESENTATION OF THE HOBBYWING QUICRUN BRUSHED ENGINE

With exceptional response and control, the Quicrun Brushed Motor is ready for your next 1/10 scale adventure. Adjustable engine timing can be selected within a range of -20° to +20° for a better driving experience.

Thanks to the high-quality materials used in the manufacturing process, the Quicrun Brushed series motors certainly meet the high demands of today's driving conditions. These include the heat-resistant magnet and built-in copper wires, which can withstand temperatures of up to 200°C. The carbons have been specially developed for an extremely long lifespan.

Another highlight is the permanently mounted PCB interference suppression boards, each with two soldered capacitors to ensure a less stressful driving experience.

These motors feel like brushless motors.

FEATURES OF THE HOBBYWING QUICRUN BRUSHED ENGINE

Modern engine for 1/10 for road and off-road
Adjustable timing (-20 to +20)
Cogging-free design
PCB included to avoid interference
Easy disassembly for maintenance work

Reference	HW30404313	HW30404314
Engine Type	540	540
Number of turns	30T	40T
Rotation speed	14,000	10,590
Max Voltage	12.6V	12.6V
Slot Number	3	3
Motor Length	53.2mm	53.2mm
Motor Diameter	36mm	36mm
Axis Diameter	3.175mm	3.175mm
Weight	168g	169g
